AP-YV3302H esd anti static electric field electricity electrostatic charge sensor
1．General
AP-YV3302 anti static sensor is a measuring device used to detect static voltage on object surface.
It adopts the advanced non-touchable crystal oscillation working style and ensures the measurement accuracy.
2. Field of application
Such anti static sensor can be widely used in electronics, opto-electrical, LED industries etc.
3. Features
(1) Comfortable hand feel and elegant appearance
(2) Measuring distance set by dial switch
(3) Wide measuring range and high measuring accuracy
(4) High clarity and comprehensive LCD data display terminal
(5) Real time monitored data transfer to PC
(6) Comfortable operation and easy to use
4. Specification
(1) Performance parameters
Model AP-YV3302
Measuring range ±10V→±4999V ±100V→±19.99KV
Measuring accuracy ±5%
Voltage drifts 5V/sec
Data transmission 1s(16 channels),62.5ms(single channel)
Corresponding velocity 0.3s
Input voltage DC24V
Measuring distance Optional(25mm,50mm,100mm,200mm,300mm,400mm,500mm,600mm,700mm)
Note:Measuring distance of 25mm,50mm are for measure static voltage less than 5KV；
Measuring distance of 100mm,200mm,300mm,400mm,500mm,600mm,700mm are for measure static voltage 5KV→20KV；
(2) Displayed information
Voltage
Distance
Address
(3) Mechanical parameters
Dimension 43*33*85mm(L*W*H)
Net weight 39.5g±3g
5. Working environment
Working temperature －18℃—＋50℃
Working humidity 0-85%RH
6. Tested data
Low measuring range(5KV)tested data:
tested data sheet:
| HV source output voltage(KV) | Sensor measured voltage(KV) |
| Test distance 25mm | Test distance 50mm | Test distance 100mm | Test distance 300mm | Test distance 600mm |
| 20 | | | 19.4 | 20 | 19.61 |
| 19.5 | | | 19.12 | 19.46 | 19.13 |
| 18.35 | | | 18.24 | 18.33 | 18.07 |
| 17.25 | | | 17.12 | 17.26 | 17.01 |
| 16.1 | | | 16 | 16.13 | 15.86 |
| 15.3 | | | 15.2 | 15.26 | 15.28 |
| 14.5 | | | 14.44 | 14.46 | 14.37 |
| 13.4 | | | 13.36 | 13.4 | 13.22 |
| 12.5 | | | 12.48 | 12.53 | 12.39 |
| 11.1 | | | 11.08 | 11.06 | 10.93 |
| 10.2 | | | 10.2 | 10.2 | 10.2 |
| 9.15 | | | 9.16 | 9.13 | 9.03 |
| 8.2 | | | 8.2 | 8.2 | 8.26 |
| 6.9 | | | 6.92 | 6.86 | 7.01 |
| 6.1 | | | 6.16 | 6.06 | 6.34 |
| 5 | 4.87 | 4.98 | 5.04 | 5 | 5.09 |
| 4.15 | 4.14 | 4.14 | 4.16 | 4.12 | 4.5 |
| 3.2 | 3.21 | 3.2 | 3.2 | 3.2 | 3.5 |
| 2.4 | 2.41 | 2.4 | 2.4 | 2.4 | 2.8 |
| 1.1 | 1.11 | 1.1 | 1.12 | 1.13 | 1.4 |
| 0.6 | 0.6 | 0.6 | 0.61 | | |
| 0.1 | 0.11 | 0.1 | 0.07 | | |
| 0.075 | 0.08 | 0.07 | 0.05 | | |
| 0 | | | | | |
| -0.075 | -0.07 | -0.05 | | | |
| -0.1 | -0.09 | -0.07 | | | |
| -0.6 | -0.59 | -0.58 | -0.52 | | |
| -1.1 | -1.09 | -1.08 | -1.04 | -1.06 | -1.35 |
| -2.4 | -2.39 | -2.4 | -2.4 | -2.4 | -2.71 |
| -3.2 | -3.19 | -3.18 | -3.2 | -3.21 | -3.44 |
| -4.15 | -4.12 | -4.16 | -4.2 | -4.12 | -4.41 |
| -5 | -5 | -5 | -5.08 | -5 | -5.08 |
| -6.1 | | | -5.96 | -6.2 | -6.33 |
| -6.9 | | | -6.88 | -7 | -7 |
| -8.2 | | | -8.24 | -8.33 | -8.25 |
| -9.45 | | | -9.2 | -9.26 | -9.06 |
| -10.2 | | | -10.2 | -10.2 | -10.22 |
| -11.1 | | | -11.12 | -11.13 | -10.95 |
| -12.5 | | | -12.52 | -12.53 | -12.4 |
| -13.4 | | | -13.44 | -13.4 | -13.22 |
| -14.5 | | | -14.52 | -14.53 | -14.41 |
| -15.3 | | | -15.32 | -15.33 | -15.3 |
| -16.1 | | | -16.12 | -16.13 | -15.91 |
| -17.25 | | | -17.2 | -17.26 | -17.1 |
| -18.35 | | | -18 | -18.33 | -18.2 |
| -19.5 | | | -19 | -19.46 | -19.2 |
| -20 | | | -20.44 | -20 | -19.6 |
